13X-PG/APG/HP for Air Separat ion
SEILY 13X molecular sieve is used to dry gas, remove H2O and CO2 for air cryo-separation industry. It has low temperature requirement for regeneration, large adsorption capacity for H2O and CO2 and a long life. We can provide it both in pallets and beads form.
Specifications
13X-PG
Item |
Unit |
Specification |
|||
Shape |
|
Pallet |
Sphere |
||
1/16” |
1/8” |
8×12 mesh |
4×6 mesh |
||
Diameter |
mm |
1.5-1.9 |
3.0-3.4 |
1.7-2.4 |
3.6-4.8 |
Bulk Density |
g/ml |
≥0.61 |
≥0.61 |
≥0.65 |
≥0.65 |
Crush Strength |
N |
≥30 |
≥70 |
≥32 |
≥80 |
CO2 Adsorpton |
wt,% |
≥16.0 |
≥16.0 |
≥16.0 |
≥16.0 |
H2O Adsorption |
wt,% |
≥24.0 |
≥24.0 |
≥24.0 |
≥24.0 |
Packing Water |
wt,% |
≤1.5 |
≤1.5 |
≤1.5 |
≤1.5 |
13X-APG
Item |
Unit |
Specification |
|||
Shape |
|
Pallet |
Sphere |
||
1/16” |
1/8” |
8×12 mesh |
4×6 mesh |
||
Diameter |
mm |
1.5-1.9 |
3.0-3.4 |
1.7-2.4 |
3.6-4.8 |
Bulk Density |
g/ml |
≥0.60 |
≥0.60 |
≥0.64 |
≥0.64 |
Crush Strength |
N |
≥30 |
≥70 |
≥30 |
≥75 |
CO2 Adsorpton |
wt,% |
≥17.5 |
≥17.5 |
≥18 |
≥18 |
H2O Adsorption |
wt,% |
≥26 |
≥26 |
≥26 |
≥26 |
Packing Water |
wt,% |
≤1.5 |
≤1.5 |
≤1.5 |
≤1.5 |
13X-HP
Item |
Unit |
Specification |
Shape |
- |
Sphere |
- |
8X12mesh |
|
Diameter |
mm |
1.7-2.4 |
Bulk Density |
g/ml |
≥0.62 |
Crush Strength |
N |
≥26 |
CO2 Adsorpton |
wt,% |
≥22 |
H2O Adsorption |
wt,% |
≥29.0 |
Packing Water |
wt,% |
≤1.5 |
Package: 55 gallon steel drum ( Net weight 150kg)
